| Outdoor Fixed Install Specification | |||||||
|
Module Specification |
Model number | 3.076-13 | 4-10S | 5-8S | 6.67-6S | 8-5S | 10-4S |
| LED lamp | SMD1415 | SMD1921 | SMD3535 | ||||
| Pixel pitch | P3.076 | P4 | P5 | P6.67 | P8 | P10 | |
| Module size | 320x160MM | ||||||
| Module resolution | 104 dots X 52 dots | 80 dots X 40 dots | 64 dots X 32 dots | 48 dots X 24 dots | 40 dots X 20 dots | 32 dots X 16 dots | |
| Module thickness | 17MM | ||||||
| Brightness | 5000cd/㎡ | 5500cd/㎡ | |||||
| Module weight | 0.46KG | 0.45KG | 0.45KG | 0.45KG | 0.44KG | 0.42KG | |
|
Cabinet Specification |
Cabinet size (W/H) | 960mm X 960mm | |||||
| Module quantity | 3pcs(W) x 6pcs(H) = 18 Pcs | ||||||
| Cabinet resolution | 312 dots X 312 dots | 240 dots X 240 dots | 192 dots X 192 dots | 144 dots X 144 dots | 120 dots X 120 dots | 96 dots X 96 dots | |
| Cabinet Pixels | 97344 dots | 57600 dots | 36864 dots | 20736 dots | 14400 dots | 9216 dots | |
| Pixel density | 105625 dots/㎡ | 62500 dots/㎡ | 40000 dots/㎡ | 22500 dots/㎡ | 15625 dots/㎡ | 10000 dots/㎡ | |
| Service access | Rear | ||||||
| Cabinet material | Die-casting Aluminum | ||||||
| Cabinet weight | 25Kg/pc | ||||||
|
Screen Parameters |
Brightness | 5000cd/㎡ | 5500cd/㎡ | 5500cd/㎡ | 5500cd/㎡ | 5500cd/㎡ | 5500cd/㎡ |
| Driving method | 1/13 Scan Constant Current | 1/10 Scan Constant Current | 1/8 Scan Constant Current | 1/6 Scan Constant Current | 1/5 Scan Constant Current | 1/4 Scan Constant Current | |
| View angle | Horizontal 140℃, Vertical 140℃ | ||||||
| Best viewing distance | 3-10M | 4-12M | 5-15M | 6.5-20M | 8-24M | 10-30M | |
| Brightness control | Red, Green and Blue 8192 Grade/Each | ||||||
| Refresh | 3840Hz | ||||||
| Input voltage | AC: 110-240V 50~60Hz | ||||||
| Defects rate | ≤0.00001 | ||||||
| Power consumption | Max.: 800W/㎡ Average: 300W/㎡ | ||||||
| MTBF | >10,000 Hours | ||||||
| Life span | ≥100,000 Hours | ||||||
| Brightness uniformity | <0.01% | ||||||
| Earth leakage current | <2mA | ||||||
| Protective grade | IP 66 | ||||||
| Color | 281 Millions | ||||||
| Output | HDMI/DVI/VGA/RGB/PbPr (HDTV) | ||||||
| Operating temperature | -20℃ to +60℃ | ||||||
| Operating humidity | 10% to 90% RH | ||||||
| Controlling system | Novastar | ||||||
| Operating system | Windows10/me/2000/NT/XP/Windows7/Vistar | ||||||
